Apix-30 |
Apix-40
|
||
|
Pixel Pitch
|
3 mm |
4 mm |
||
|
Pixel Density
|
111,111 pixels/sq.m |
62,500 pixels / sq.m |
||
|
LED Type
|
|
SMD 1921, 3 in 1 |
|
|
|
Panel Size
|
840 x 1950 mm |
1090 x 1900 mm |
||
|
Panel Resolution
|
256p x 480p |
256p x 352p |
||
|
Panel Matarial
|
Aluminum |
|||
|
Panel Weight
|
≤ 50 kg/sq.m |
|||
|
Power Consumption Max
|
780 W/㎡ |
|||
|
Power Consumption Average
|
230 W/㎡ |
|||
|
Driving Mode
|
1/16 |
1/8 |
||
|
Color Depth (bit)
|
14 bit |
|||
|
Brightness
|
≥ 4500 nits |
|||
|
Optimal Minimum View Distance
|
≥ 3 meters |
≥ 4 meters |
||
|
Refresh Rate
|
≥ 1920 Htz |
|||
|
View Angle
|
H 160° / V 160° |
|||
|
Power Input
|
AC 110/220, ±10%, 50/60 Htz |
|||
|
Operation Temperature
|
-30 ~ 60 ℃ |
|||
|
Ingress Protection
|
IP65 |
|||
|
Display Mode
|
Asynchronous (USB/Cable/WIFI/4G, optional) |
|||
 |
